Narrow Body Interchangeable Multi-Head Towbar

Product Description

Part Number: 2001056

Alternative Part Numbers: 001693 & 01-1322-0000

Our quick change narrow body multi-head towbar designed for use with the interchangeable narrow body multi-head aircraft heads, which are available separately.

Multi-heads are available in various clamp or pin-type configurations. Multi-heads designed to fit this towbar:

001694 / 2001057: Airbus A318/A319/A320/A321

001695 / 2001058: Airbus A300/A310, Boeing B727

001696 / 2001059: Boeing B757

001697 / 2001060: Fokker F70/F100

001698 / 2001061: Boeing B717/ Boeing/McDonnell Douglas MD-80/DC-9

001699 / 2001062: Boeing B737 100-900, BBJ Series

002282 / 2001529: Boeing B737 600-900, BBJ Series (“Overbite Style”)

000616 / 2000369: Embraer 170-195 Series, Lineage 1000 (with adapter 2001555)

Note: Towbar is shown with 001696 Boeing 757 Towbar Head

Note: Crating is recommended for protection of towbars during transit.

Please contact Aviation Spares & Repairs Limited for more information on the narrow body multi-head towbar. We are here to help with all your GSE requirements.

• 8″ x 15′ (20.32 cm x 4.57 m) aluminium tube
• Hydraulic retractable running gear
• Durable powder coated paint

Crating is recommended for protection of towbars during transit. We accept no liability for damage during transit of un-crated towbars .

Dimensions:

• Size: L 216″ x W 26″ x H 20″ (5.49 m x 66.04 cm x 50.8 cm)
• Crated Size: L 216″ x W 26″ x H 26″ (5.49 m x 66.04 cm x 66.04 cm)
• Weight:350 lbs (158.76 kg)
• Crated Weight: 570 lbs (258.55 kg)
