DOCS 500 Deployable Oxygen Concentration System

Product Description

Deployable Oxygen Concentration System (DOCS) 500 offers the lowest cost per ccf of oxygen generated of any oxygen generator its size class.

Advantages

• Lowest power consumption and maintenance cost in the market place
• Very compact & versatile
• Provides 4m3 per hour of USP 93% oxygen
• Remote system diagnostics capability
• Can be delivered as turn-key system, eliminating on-site installation
• FDA 510(k) clearance

Please contact Aviation Spares & Repairs Limited for more information on the DOCS 500. We are here to help with all your GSE requirements.

Discharge flow rate¹

500 lpm | 30 m³ per hour | 1060 scfh | 2100 lbs per day | 954 kg per day

O₂ purity @ discharge flow rate

93% +/- 3%

O₂ output pressure

20 – 100 psig | 1.4 – 6.9 barg

Operating temperature

0°F to 120°F | -18°C – 49°C

Power requirements

Site power source: 380/460 VAC +/- 10%, 50/60 Hz +/- 3%, 3-Phase, 120/100 Ampere
Plant: 380/460 VAC , 50/60 Hz, 3-Phase, 100/80 FLA

Average power consumption

17.1 kW at 20 psig (1.4 barg) output pressure
17.5 kW at 55 psig (3.8 barg) output pressure
18.9 kW at 100 psig (6.9 barg) output pressure

Process outlet connection

3/4” Internal NPT Fitting

Dimensions

Unit footprint dimensions (nom.) 76” L x 119” W x 81” H | 193 cm L x 302 cm W x 207 cm H
Crated dimensions (nom.)
Crate 1 82” L x 67” W x 91” H | 208 cm L x 170 cm W x 231 cm H
Crate 2 85” L x 82” W x 91” H | 216 cm L x 208 cm W x 231 cm H

Weight

Unit weight (nom.) 5,958 lbs | 2702 kg
Crated Weight (nom.) Crate 1: 3,000 lbs | 1362 kg | Crate 2: 5,300 lbs | 2406 kg

Average Costs

Average scheduled maintenance cost

$160 – $180 per month

Average operating cost @ 55 psig

$0.16 – $0.23 per 100 scf | $0.06 – $0.08 per m³

1. Performance parameters stated at standard conditions (59°F 14.7 psia 0% RH I 15°C 101.325kPa 0% RH). Operation in atypical conditions may affect performance. For more information, please consult with your PCI technical representative.

2. Available in CE compliant configuration.

3. Electrical enclosure cUL listed.

• Remote monitoring & diagnostics suite
• 4-20 mA Communication to external controller (0-10V standard)
• Mass flow control assembly
• Automatic sleep mode feature for low-demand situations
• Platinum 3 plus 10 Warranty
