JP100SSC – 100,000 lb Capacity

Product Description

We took the world’s best turning radius and smoothest deceleration JP100S and added Softcapture ® technology. Approach and capture with no straps and no contact with the landing gear. Capture is as simple as two arms gently wrapping around the tires, locking and lifting in one smooth action.

Standard Features:

  • Connect to the aircraft nose landing gear without leaving the operator station
  • All contact is made on the nose landing gear tires only, no contact or straps on the oleo strut
  • Automatic oversteer protection sensors
  • Dual, 10 hp motors on the front tractive wheels are “independently” excited and provide a few benefits
  • Reversing the inside wheel and speeding up the outside wheel creates the best turning radius, virtually eliminated wingtip shift
  • Capture and spot aircraft with only one approach.
  • Smooth deceleration regen-braking creates a shorter, smoother stop, no hard stops like others
  • Sit down model (forward reverse option available)
  • Headlights and rear facing LED lights
  • LED Strobe light and side marker lights
  • Suspension system dampens transmitted vibration for passengers, crew and operator
  • Suspension seats for operator and passenger
  • Two packs of Eight deep cycle 6V batteries
  • Low maintenance, solid rubber tires
  • Fire Extinguisher
  • Automatic activated/deactivated parking brake

Softcapture ® Safety Features:

  • Oversteer protection
  • Throttle speed limit safety switch reduces speed when approaching the aircraft with cradle down
  • Forward motion safety switch disengages the throttle when the forward motion safety bar contacts the aircraft nose tire preventing the operator from pushing on the nose tire
  • The gate lock and cradle locator safety switch locates the cradle and stops the “cradle down” movement when the cradle is lowered to the ground. The gate lock prevents “cradle open” movement when the cradle is up
  • The parking brake release safety switch allows the JetPorter to “roll” during capture so the aircraft doesn’t move, the hydraulic foot brake remains functional at all times
  • Controlled acceleration and deceleration foot pedal operated throttle

Charger Option:

  • Single phase AC fully automatic
    • AMETEK Battery Charger JP-204-50 (50 Hz) or JP-204-60 (60 Hz)

Please contact Aviation Spares & Repairs Limited for more information on the JP100SSC. We are here to help with all of your GSE needs.


  • Towing capacity: 100,000 lbs (45,359 kg)
  • Cradle capacity: 10,000 lbs (4,536 kg)
  • Empty speed: 6.5 mph (10.5 kph)
  • Full load speed: 3 mph (4.8 kph)
  • Motor horsepower: 20 HP
  • Motor duty cycle: Continuous
  • Battery type: Sixteen – 6 volt deep
  • Charge time full discharge: 8 hour average
  • Length: 207.2″(5.26 m)
  • Width: 70″ (1.77 m)
  • Height: 38.9″ (0.98 m)
  • Weight with battery: 7000 lbs (3175 kg)
  • Weight without battery: 5000 lbs (2268 kg)
  • Ground clearance: 5.4″ (13.7 cm)
  • Deck height: 24.2″ (61.6 cm)
  • Cradle captures: 18″ – 24″ (45.7 cm – 60.9 cm) double wheel
  • Cradle width: 30″ (76.2 cm)
  • Cradle lift height: 7″ (76.8 cm)
  • Steering tires: 4 x 8 (16″ O.D.)
  • Drive tires: 21 X 8 X 15
  • Brakes: Regenerative dynamic motor braking and manual hydraulic foot brake
  • Parking brakes: Automatic activated/deactivated

Accessories list

  • Battery charger
  • Jumper cable
  • Air compressor
  • Forward & reverse steering option

Aircraft adapters

  • West wind
  • MU-2
  • Falcon 7X
  • Falcon 50/900/2000
  • Lear 40/45
  • Dash 8-400
